E系列-C6500
發(fā)布日期:2024-01-09 瀏覽次數(shù):502
ITEM | P/N | Y HEX | T1 | M1 | D1 | T2 | M2 | D2 | T3 | M3 | D3 |
1 | C6500-02-02-02-FG | 0.438 | 5/16-24UNF | 0.77 | 0.093 | 5/16-24UNF | 0.77 | 0.093 | 5/16-24UNF | 0.77 | 0.093 |
2 | C6500-03-03-03-FG | 0.438 | 3/8-24UNF | 0.83 | 0.125 | 3/8-24UNF | 0.83 | 0.125 | 3/8-24UNF | 0.83 | 0.125 |
3 | C6500-04-04-04-FG | 0.438 | 7/16-20UNF | 0.89 | 0.203 | 7/16-20UNF | 0.89 | 0.203 | 7/16-20UNF | 0.89 | 0.203 |
4 | C6500-05-05-05-FG | 0.562 | 1/2-20UNF | 0.95 | 0.234 | 1/2-20UNF | 0.95 | 0.234 | 1/2-20UNF | 0.95 | 0.234 |
5 | C6500-06-06-06-FG | 0.562 | 9/16-18UNF | 1.05 | 0.281 | 9/16-18UNF | 1.05 | 0.281 | 9/16-18UNF | 1.05 | 0.281 |
6 | C6500-08-08-06-FG | 0.75 | 3/4-16UNF | 1.25 | 0.422 | 3/4-16UNF | 1.25 | 0.422 | 9/16-18UNF | 1.14 | 0.281 |
7 | C6500-08-08-08-FG | 0.75 | 3/4-16UNF | 1.25 | 0.391 | 3/4-16UNF | 1.25 | 0.391 | 3/4-16UNF | 1.25 | 0.391 |
8 | C6500-10-10-08-FG | 0.875 | 7/8-14UNF | 1.42 | 0.5 | 7/8-14UNF | 1.42 | 0.5 | 3/4-16UNF | 1.35 | 0.422 |
9 | C6500-10-10-10-FG | 0.875 | 7/8-14UNF | 1.42 | 0.500 | 7/8-14UNF | 1.42 | 0.500 | 7/8-14UNF | 1.42 | 0.500 |
10 | C6500-12-12-12-FG | 1.062 | 1-1/16-12UNF | 1.58 | 0.656 | 1-1/16-12UNF | 1.58 | 0.656 | 1-1/16-12UNF | 1.58 | 0.656 |
11 | C6500-14-14-14-FG | 1.312 | 1-3/16-12UNF | 1.66 | 0.719 | 1-3/16-12UNF | 1.66 | 0.719 | 1-3/16-12UNF | 1.66 | 0.719 |
12 | C6500-16-16-16-FG | 1.312 | 1-5/16-12UNF | 1.73 | 0.875 | 1-5/16-12UNF | 1.73 | 0.875 | 1-5/16-12UNF | 1.73 | 0.875 |
13 | C6500-32-32-32-FG | 2.5 | 2-1/2-12UN | 2.45 | 1.813 | 2-1/2-12UN | 2.45 | 1.813 | 2-1/2-12UN | 2.45 | 1.813 |
